Description
Low voltage and high current 20kW charging module, MXR200150
MXR200150 is a low-voltage and high-current charging power module, which has the outstanding advantages of ultra-wide output voltage range and ultra-large charging current. At the same time, high reliability, high efficiency, high power factor, high power density, wide output voltage range, Wide working temperature and low standby power consumption are also the main features of the module.
Main features
Wide output voltage range, 20-100VDC, suitable for low-speed EVs;Wide operating temperature range at full power,-40℃~50℃;Full load efficiency is higher than 95%, high efficiency in the whole working range, and more energy saving;Ultra-low standby power consumption, the whole series of produces are controlled within 8W;The current in the low-voltage area does not shrink, and the charging speed is faster;
The module is built with residual pressure relief loop to reduce system cost and improve system reliabilit
