MXR150060BL-DC is a 60kW liquid-cooled DC power supply module designed with advanced third-generation silicon carbide (SiC) devices. Backed by over 10 years of power electronics expertise, it offers a wide input range of 450–920Vdc and an ultra-high output voltage of up to 1500Vdc. With high conversion efficiency, strong environmental protection, and stable performance, it is ideal for high-voltage EV charging and DC energy systems.
MXR150060BL-DC 60 kw 1500V dc dc converter power supply module
Description
Input Voltage: 450Vdc~920Vdc
Input Current: ≤82A
Output Power: 60kw
Output Voltage Range: 200～1500Vdc Continuously adjustable
Output Current Range: 0～160A Continuously adjustable
Voltage stabilised accuracy: ≤±0.5%
Current stabilised accuracy: ≤±1%
Ripple Peak to Peak: ≤1%
Operating Temperature: -40~70℃
Altitude: Full load output below 2000m
Size(W×D×H): 410×500×132mm
Weight: <48kg
Efficiency(full load): >97%
Cooling Mode: Liquid cooling
Communication Method: CAN
Parallel Module Quantity: 60 (Special customisation available)
Coolant: Coolant Options: Deionised Water, Water-Ethylene Glycol Mixture Inlet Coolant Temperature: Less than 70°C Coolant Flow Rate: 10 litres per minute (L/min)
