Description
Input Voltage: 285-475Vac, three-phase + PE
Power Factor: ≥0.95(4kw≤output power≤10kw); ≥0.98(10kw≤output power≤20kw)
ITHD: ≤5%(10kw≤output power≤20kw)
Output Voltage Range: 50-1000Vdc
Output Current Range: 0-67A continuously regulated
Voltage stabilised accuracy: ≤±0.5%(regulated state, input voltage 323Vac~456Vac, output voltage 200Vdc~1000Vdc, output current 0~Rated current value)
Current stabilised accuracy: ≤±1%(steady current state, input voltage 323Vac~456Vac, output voltage 200~1000Vdc, output current 20% rated current~100% rated current value)
Current Sharing Imbalance: ≤±5%
Ripple Peak to Peak: ≤±1%(regulated state, input voltage 323Vac~456Vac, output voltage 200Vdc~1000Vdc, output current 0~rated current )
Operating Temperature: -40℃～75℃, output derating above 60℃
Storage Temperature: -40℃～+75℃
Relative Humidity: ≤95% RH without condensation
Altitude: ≤2000m without detating, ＞2000m, the working temperature decrease by 1℃ for every 100 meters
Size(W×D×H): 218×459×84mm
Efficiency(full load): >95.5%
Cooling Mode: Fan cooling
Standby Power consumption: 8.5W+/-0.5W
Communication Method: CAN bus
Parallel Module Quantity: ≤60 pieces
Indicator: Green: normal operation Yellow: alarm Red: fault
Certification: CE/Dekra/EMC
