LRG1K0100G Ac dc Power Module 30kw Liquid Cooling EV Charger Module

Description

Main features:

1. liquid cooling for higher protection and reliability
2. anti condensation water design
3. zero audio noise
4. high frequency transformer isolation
5. full hot plug design
6. wide output range of voltage from 150V to 1000V, workable on a wide range of electric vehicles
7. constant current for higher output power at low output voltage
8. full load efficiency above 96.5%
9. intelligent automatic discharging of residual charge
10. super standby power consumption 2W
11. ambient temperature from -40ºC to +75ºC
12.  input voltage from 260V to 530V, allowing normal function under most poor grid conditions
13. CAN bus communication, max 48 power modules in parallel
14. alarm and protection: 1. over/under voltage leads to automatic shutdown and power module will restart after voltage resumes normal; 2. over/short circuit leads to automatic shotdown and lock, and will restart after power off; 3. over temperature leads to automatic shotdown and power module will restart after temperature resumes normal.
