7Kw single gun AC Charger

SKU AW32

£445.00

  • Flash Sale

0
0
0
0
Days
0
0
Hrs
0
0
Min
0
0
Sec

Description

Phihong 32A single gun AC Charger.



  • Stylish, ergonomic and customizable design
  • Input : 200Vac~240Vac
  • RFID card reader for user identification and management
  • Optional wired/wireless connection for back office management
  • Ideal choices for residential community and commercial EV charging
  • IP55 rated for indoor/outdoor applications
  • Firmware updates through remote connection
  • SAE J1772(Type 1) or IEC 62196-2(Type 2)
Applications
  • Highway gas / service station
  • Parking garage
  • EV dealer workshops
  • Commercial fleet operators
  • EV infrastructure operators / service providers
LAN + RFID (+OCPP for AW32) = £139
LAN + WIFI (+OCPP for AW32) = £163
LAN + 4G (+OCPP for AW32) = £200



Specification
AW series
Model No.
AWSE770
AWLU770
AWSC770
AC Input
Input Rating
200~240Vac/Single phase
AC Input Connection
L/N/PE
L1/L2/GND
L1/L2/GND
Max. Input Current (A)
32
Frequency (Hz)
50 / 60
AC Output
Max Output Current
32A
User Interface & Control
Display Information
RFID(ISO / IEC 14443A / B, ISO / IEC 15693, FeliCa ™ 1, NFC, Mifare)
Communication
External
LAN (optional) / LAN + 4G (optional) or Wi-Fi (optional)
Internal
OCPP 1.6 JSON
Environmental
Operating Temperature (°C)
-30 ~ 50
Humidity (%)
Max. 90% RH
Altitude (m)
≦ 2000m
IP Level
IP55
NEMA TYPE 3R
IP55
Cooling method
Natural Cooling
Mechanical
Dimension (WxDxH mm)
290 x 120 x 410
Weight (kg)
≦ 4 (without Gun)
Cable Length(m)
5
Protection
Input Protection
UVP, OVP, Ground fault
Output Protection
OCP & RCD
Internal
OTP、Relay welding detection、MCU function fault detection
Regulation
Certificate
IEC 61851-1:2017IEC61851-21-2:2018
UL2594,UL2231-1 / -2
CNS 15511-1:2017CNS 15511-2:2010CNS 15511-3:2012CNS 15511-22:2017
Safety
CE
UL / cUL
CNS
Charging Interface
IEC 62196-2-2016Type 2 Plug
SAEJ1772 Type 1 Plug
SAEJ1772 Type 1 Plug
